images-replaced — 100.00% verified visual parity

← all categories · PASS 38 · FAIL 0 · REFERENCE-DISPUTED 0 · 38 total · 300 DPI

diff colours:MissingExtraColorErrMatchFull-page diff: matching and per-channel ≤1.0% pixels are blank; coloured classes are same-coordinate above-floor evidence. Exact RGBA mismatch remains numeric.

show PASS 38status class min diff% sort

aspect-ratio — 100.00% verified visual parity PASS 1 · FAIL 0 · REFERENCE-DISPUTED 0all categories ↑

PASS exact match img-aspect-ratio-box · fixed-width-derived-height

A box with width:200px and aspect-ratio:2/1, expected to derive a 100px height.

fragmentation — 100.00% verified visual parity PASS 2 · FAIL 0 · REFERENCE-DISPUTED 0all categories ↑

PASS exact match img-monolithic-page-push · monolithic-image-push · 2 pages

page 1

page 2

A block image too tall for the remaining space after the filler is pushed WHOLE to page 2 (spec-correct class-A break before a monolithic box), not split or clipped. The multi-page harness asserts both pages.

PASS exact match img-taller-than-page-sliced · monolithic-image-slice · 3 pages

page 1

page 2

page 3

A block image taller than a full page content box is SLICED across 3 pages (css-break-3 §4.1: monolithic content taller than the fragmentainer slices at its edge). Each page embeds only its own vertical band of the source raster, not a full copy. The multi-page harness asserts all three pages.

image-orientation — 100.00% verified visual parity PASS 1 · FAIL 0 · REFERENCE-DISPUTED 0all categories ↑

PASS visually equivalent · no rejecting defect · thresholded evidence 0.44% · raw 0.96% (1829 px) img-image-orientation-rotate · rotate-90deg-before-fitPASS via CSS-scale observation: stable same-coordinate outline phaseColorValuemissing 0.002528%extra 0.001264%ΔE 0.2

why: visually accepted coverage phase; raw fill recolour ΔRGB(-1,+0,+0) (ΔE 0.2)

image-orientation:90deg rotates the raster before object-fit:contain sizing; catches ignoring the orientation property.

regions (3 total; showing 3 representatives)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	1	1826	43,22 → 90,68	1826	total 2.3% · largest 2.3% · max ΔE 0.2
Extra	1	1	90,22 → 90,22	1	total 0.001262% · largest 0.001262%
Missing	1	2	90,68 → 90,68	2	total 0.002524% · largest 0.002524%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
ColorValue	43,22 → 90,68	2.3	ΔE 0.2 ΔRGB(-1,0,0)	fill recolour ΔRGB(-1,+0,+0) (ΔE 0.2)
Missing	90,68 → 90,68	0.002524		candidate lacks paint present in reference (0.002524%)
Extra	90,22 → 90,22	0.001262		candidate adds paint absent from reference (0.001262%)

source · cases/images-replaced/img-image-orientation-rotate.html

1<!DOCTYPE html>
2<html lang="en">
3<head>
4<meta charset="utf-8">
5<style>
6  @page { size: 144px 136px; margin: 0; }
7  html { font-family: ParitySans; line-height: 1.5; }
8  * { margin: 0; box-sizing: border-box; }
9  html, body { background: #ffffff; }
10  .slot {
11    width: 90px;
12    height: 90px;
13    background: #c62828;
14  }
15  .slot img {
16    display: block;
17    width: 90px;
18    height: 90px;
19    object-fit: contain;
20    image-orientation: 90deg;
21    image-rendering: pixelated;
22  }
23</style>
24</head>
25<body>
26  <div class="slot">
28  </div>
29</body>
30</html>

image-rendering — 100.00% verified visual parity PASS 1 · FAIL 0 · REFERENCE-DISPUTED 0all categories ↑

PASS exact match img-image-rendering-pixelated · pixelated

image-rendering:pixelated scales a 2x2 raster to a hard-edged 120px image; catches smoothing the scaled pixels.

img — 100.00% verified visual parity PASS 14 · FAIL 0 · REFERENCE-DISPUTED 0all categories ↑

PASS visually equivalent · no rejecting defect · thresholded evidence 0.43% · raw 0.47% (2808 px) img-height-scaled · height-auto-width-aspectPASS via CSS-scale observation: sub-CSS shared-colour coverageColorValueΔE 17.4

why: visually accepted coverage phase; raw fill recolour ΔRGB(+0,+14,-1) (ΔE 17.4)

A 2:1 intrinsic image with height:90px and width:auto derives width:180px from the aspect ratio.

regions (1 total; showing 1 representative)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	1	2808	0,0 → 180,90	2808	total 1.2% · largest 1.2%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
ColorValue	0,0 → 180,90	1.2	ΔRGB(0,14,-1)	fill recolour ΔRGB(+0,+14,-1) (ΔE 0)

source · cases/images-replaced/img-height-scaled.html

1<!DOCTYPE html>
2<html lang="en">
3<head>
4<meta charset="utf-8">
5<title>img height scaled aspect preserved</title>
6<style>
7  @page { size: 400px 152px; margin: 0; }
8  html { font-family: ParitySans; line-height: 1.5; }
9  * { margin: 0; box-sizing: border-box; }
10  html, body { background: #ffffff; }
11  .stage { width: 260px; margin: 30px; background: #eeeeee; }
12  /* height set, width auto: a 2:1 intrinsic image stays 2:1, so height:90px
13     derives width:180px from the aspect ratio. */
14  img {
15    display: block; width: auto; height: 90px; image-rendering: pixelated;
16  }
17</style>
18</head>
19<body>
20  <div class="stage">
22  </div>
23</body>
24</html>

PASS visually equivalent · no rejecting defect · thresholded evidence 0.43% · raw 0.47% (2808 px) img-width-scaled · width-auto-height-aspectPASS via CSS-scale observation: sub-CSS shared-colour coverageColorValueΔE 17.4

why: visually accepted coverage phase; raw fill recolour ΔRGB(+0,+14,-1) (ΔE 17.4)

A 2:1 intrinsic PNG with width:180px and height:auto, preserving aspect ratio at 180x90.

regions (1 total; showing 1 representative)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	1	2808	0,0 → 180,90	2808	total 1.2% · largest 1.2%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
ColorValue	0,0 → 180,90	1.2	ΔRGB(0,14,-1)	fill recolour ΔRGB(+0,+14,-1) (ΔE 0)

source · cases/images-replaced/img-width-scaled.html

1<!DOCTYPE html>
2<html lang="en">
3<head>
4<meta charset="utf-8">
5<title>img width scaled aspect preserved</title>
6<style>
7  @page { size: 400px 152px; margin: 0; }
8  html { font-family: ParitySans; line-height: 1.5; }
9  * { margin: 0; box-sizing: border-box; }
10  html, body { background: #ffffff; }
11  .stage {
12    width: 260px;
13    margin: 30px;
14    background: #eeeeee;
15  }
16  /* width set, height auto: a 2:1 intrinsic image stays 2:1 (180x90). */
17  img {
18    display: block;
19    width: 180px;
20    height: auto;
21    image-rendering: pixelated;
22  }
23</style>
24</head>
25<body>
26  <div class="stage">
28  </div>
29</body>
30</html>

PASS visually equivalent · no rejecting defect · thresholded evidence 0.37% · raw 0.41% (1558 px) img-percent-width · percentage-widthPASS via CSS-scale observation: sub-CSS shared-colour coverageColorValueΔE 15.3

why: visually accepted coverage phase; raw fill recolour ΔRGB(+0,+8,-1) (ΔE 15.3)

width:50% on a 2:1 image resolves against the 200px containing block to 100px wide, deriving a 50px height.

regions (1 total; showing 1 representative)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	1	1558	0,0 → 100,50	1558	total 1.6% · largest 1.6%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
ColorValue	0,0 → 100,50	1.6	ΔRGB(0,8,-1)	fill recolour ΔRGB(+0,+8,-1) (ΔE 0)

source · cases/images-replaced/img-percent-width.html

1<!DOCTYPE html>
2<html lang="en">
3<head>
4<meta charset="utf-8">
5<title>img percentage width</title>
6<style>
7  @page { size: 344px 112px; margin: 0; }
8  html { font-family: ParitySans; line-height: 1.5; }
9  * { margin: 0; box-sizing: border-box; }
10  html, body { background: #ffffff; }
11  .stage { width: 200px; margin: 30px; background: #eeeeee; }
12  /* width:50% of the 200px containing block = 100px wide; height auto keeps the
13     2:1 aspect ratio so the image is 100x50. */
14  img { display: block; width: 50%; height: auto; image-rendering: pixelated; }
15</style>
16</head>
17<body>
18  <div class="stage">
20  </div>
21</body>
22</html>

PASS visually equivalent · no rejecting defect · thresholded evidence 0.03% · raw 0.03% (206 px) svg-as-img · svg-data-uri-sourcePASS via CSS-scale observation: sub-CSS shared-colour coverageAntialiasCoverageΔE 3.4

why: visually accepted coverage phase; raw antialiasing coverage residue on a shared outline

An SVG document referenced as the src of an img via a data: URI, drawn at 160x120.

regions (146 total; showing 64 representatives)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	146	206	10,20 → 90,100	6	total 0.07% · largest 0.002133%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
AntialiasCoverage	31,24 → 32,24	0.002133	ΔRGB(-12,-9,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	67,24 → 68,24	0.002133	ΔRGB(-12,-9,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	38,21 → 38,21	0.001067	ΔRGB(-12,-9,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	61,21 → 62,21	0.001067	ΔRGB(-12,-9,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	14,42 → 14,43	0.001067	ΔRGB(-18,-13,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	86,42 → 86,43	0.001067	ΔRGB(-18,-13,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	12,46 → 12,47	0.001067	ΔRGB(-11,-7,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	87,46 → 88,47	0.001067	ΔRGB(-11,-7,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	12,47 → 12,48	0.001067	ΔRGB(-11,-7,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	88,47 → 88,48	0.001067	ΔRGB(-11,-7,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	32,96 → 32,96	0.001067	ΔRGB(-17,-12,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	67,96 → 68,96	0.001067	ΔRGB(-17,-12,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	36,98 → 37,98	0.001067	ΔRGB(-11,-7,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	63,98 → 63,98	0.001067	ΔRGB(-11,-7,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	37,98 → 38,98	0.001067	ΔRGB(-14,-10,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	61,98 → 62,98	0.001067	ΔRGB(-14,-10,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	36,22 → 36,22	0.000711	ΔRGB(-12,-9,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	63,22 → 63,22	0.000711	ΔRGB(-12,-9,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	34,23 → 34,23	0.000711	ΔRGB(-10,-8,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	66,23 → 66,23	0.000711	ΔRGB(-10,-8,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	14,41 → 14,42	0.000711	ΔRGB(-5,-4,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	85,41 → 85,42	0.000711	ΔRGB(-5,-4,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	13,44 → 13,44	0.000711	ΔRGB(-10,-8,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	87,44 → 87,44	0.000711	ΔRGB(-10,-8,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	11,49 → 11,49	0.000711	ΔRGB(-8,-6,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	88,49 → 88,49	0.000711	ΔRGB(-8,-6,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	12,72 → 12,72	0.000711	ΔRGB(-8,-5,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	88,72 → 88,72	0.000711	ΔRGB(-8,-5,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	12,73 → 12,73	0.000711	ΔRGB(-8,-5,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	88,73 → 88,73	0.000711	ΔRGB(-8,-5,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	14,77 → 14,77	0.000711	ΔRGB(-21,-15,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	86,77 → 86,77	0.000711	ΔRGB(-21,-15,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	14,78 → 14,78	0.000711	ΔRGB(-17,-12,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	85,78 → 85,78	0.000711	ΔRGB(-17,-12,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	31,95 → 32,95	0.000711	ΔRGB(-17,-12,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	68,95 → 68,95	0.000711	ΔRGB(-17,-12,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	35,97 → 35,97	0.000711	ΔRGB(-5,-4,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	65,97 → 65,97	0.000711	ΔRGB(-5,-4,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	45,20 → 45,20	0.000356	ΔRGB(-18,-13,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	55,20 → 55,20	0.000356	ΔRGB(-18,-13,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	43,20 → 43,20	0.000356	ΔRGB(-17,-12,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	57,20 → 57,20	0.000356	ΔRGB(-17,-12,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	41,21 → 41,21	0.000356	ΔRGB(-17,-12,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	59,21 → 59,21	0.000356	ΔRGB(-17,-12,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	39,21 → 39,21	0.000356	ΔRGB(-11,-7,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	60,21 → 60,21	0.000356	ΔRGB(-11,-7,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	37,22 → 37,22	0.000356	ΔRGB(-8,-5,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	37,22 → 37,22	0.000356	ΔRGB(-17,-12,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	62,22 → 62,22	0.000356	ΔRGB(-17,-12,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	63,22 → 63,22	0.000356	ΔRGB(-8,-5,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	35,22 → 35,22	0.000356	ΔRGB(-4,-3,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	36,22 → 36,22	0.000356	ΔRGB(-16,-12,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	64,22 → 64,22	0.000356	ΔRGB(-16,-12,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	65,22 → 65,22	0.000356	ΔRGB(-4,-3,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	35,23 → 35,23	0.000356	ΔRGB(-14,-10,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	65,23 → 65,23	0.000356	ΔRGB(-14,-10,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	30,25 → 30,25	0.000356	ΔRGB(-11,-7,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	69,25 → 69,25	0.000356	ΔRGB(-11,-7,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	30,25 → 30,25	0.000356	ΔRGB(-8,-6,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	70,25 → 70,25	0.000356	ΔRGB(-8,-6,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	28,26 → 28,26	0.000356	ΔRGB(-16,-12,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	71,26 → 71,26	0.000356	ΔRGB(-16,-12,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	26,28 → 26,28	0.000356	ΔRGB(-14,-10,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	74,28 → 74,28	0.000356	ΔRGB(-14,-10,-2)	antialiasing coverage residue on a shared outline

source · cases/images-replaced/svg-as-img.html

1<!DOCTYPE html>
2<html lang="en">
3<head>
4<meta charset="utf-8">
5<title>svg as img data uri</title>
6<style>
7  @page { size: 384px 184px; margin: 0; }
8  html { font-family: ParitySans; line-height: 1.5; }
9  * { margin: 0; box-sizing: border-box; }
10  html, body { background: #ffffff; }
11  .stage {
12    width: 240px;
13    margin: 30px;
14    background: #eeeeee;
15  }
16  /* SVG document referenced through an img element via a data: URI, drawn at 160x120. */
17  img {
18    display: block;
19    width: 160px;
20    height: 120px;
21  }
22</style>
23</head>
24<body>
25  <div class="stage">
27  </div>
28</body>
29</html>

PASS visually equivalent · no rejecting defect · thresholded evidence 0.02% · raw 0.02% (44 px) images-replaced-img-in-table-cell · img-inside-table-cellPASS via CSS-scale observation: one-sided sub-CSS outline coverageAntialiasCoveragemissing 0.01%ΔE 3.8

why: visually accepted coverage phase; raw antialiasing coverage residue on a shared outline

An SVG img replaced element inside a bordered table cell paints at its laid-out size; catches table-cell paint walkers that lay out but drop replaced-image children.

regions (36 total; showing 36 representatives)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	32	40	21,21 → 53,53	2	total 0.04% · largest 0.001777%
Missing	4	4	23,23 → 53,53	1	total 0.003555% · largest 0.000889%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
AntialiasCoverage	44,22 → 44,22	0.001777	ΔRGB(17,10,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	51,29 → 51,29	0.001777	ΔRGB(19,12,6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	22,44 → 22,44	0.001777	ΔRGB(17,10,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	52,44 → 52,44	0.001777	ΔRGB(19,12,6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	51,45 → 51,45	0.001777	ΔRGB(19,12,6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	29,51 → 29,51	0.001777	ΔRGB(19,12,6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	45,51 → 45,51	0.001777	ΔRGB(19,12,6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	44,52 → 44,52	0.001777	ΔRGB(19,12,6)	antialiasing coverage residue on a shared outline
Missing	45,23 → 45,23	0.000889		candidate lacks paint present in reference (0.000889%)
Missing	53,35 → 53,35	0.000889		candidate lacks paint present in reference (0.000889%)
Missing	23,45 → 23,45	0.000889		candidate lacks paint present in reference (0.000889%)
Missing	35,53 → 35,53	0.000889		candidate lacks paint present in reference (0.000889%)
AntialiasCoverage	35,21 → 35,21	0.000889	ΔRGB(18,12,7)	antialiasing coverage residue on a shared outline
AntialiasCoverage	39,21 → 39,21	0.000889	ΔRGB(15,10,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	32,22 → 32,22	0.000889	ΔRGB(15,10,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	42,22 → 42,22	0.000889	ΔRGB(10,7,3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	30,22 → 30,22	0.000889	ΔRGB(31,21,11)	antialiasing coverage residue on a shared outline
AntialiasCoverage	29,23 → 29,23	0.000889	ΔRGB(15,10,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	45,23 → 45,23	0.000889	ΔRGB(18,12,7)	antialiasing coverage residue on a shared outline
AntialiasCoverage	29,23 → 29,23	0.000889	ΔRGB(19,12,6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	23,29 → 23,29	0.000889	ΔRGB(19,12,6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	23,29 → 23,29	0.000889	ΔRGB(15,10,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	22,30 → 22,30	0.000889	ΔRGB(31,21,11)	antialiasing coverage residue on a shared outline
AntialiasCoverage	52,30 → 52,30	0.000889	ΔRGB(38,25,13)	antialiasing coverage residue on a shared outline
AntialiasCoverage	22,32 → 22,32	0.000889	ΔRGB(15,10,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	52,32 → 52,32	0.000889	ΔRGB(19,12,6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	21,35 → 21,35	0.000889	ΔRGB(18,12,7)	antialiasing coverage residue on a shared outline
AntialiasCoverage	21,39 → 21,39	0.000889	ΔRGB(15,10,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	53,39 → 53,39	0.000889	ΔRGB(19,12,6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	22,42 → 22,42	0.000889	ΔRGB(10,7,3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	52,42 → 52,42	0.000889	ΔRGB(14,9,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	23,45 → 23,45	0.000889	ΔRGB(18,12,7)	antialiasing coverage residue on a shared outline
AntialiasCoverage	30,52 → 30,52	0.000889	ΔRGB(38,25,13)	antialiasing coverage residue on a shared outline
AntialiasCoverage	32,52 → 32,52	0.000889	ΔRGB(19,12,6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	42,52 → 42,52	0.000889	ΔRGB(14,9,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	39,53 → 39,53	0.000889	ΔRGB(19,12,6)	antialiasing coverage residue on a shared outline

source · cases/images-replaced/images-replaced-img-in-table-cell.html

1<!DOCTYPE html><html><head><meta charset='utf-8'><style>
2@page{size:224px 120px;margin:0}
3html{font-family:ParitySans;line-height:1.5}
4*{margin:0;box-sizing:border-box}
5body{padding:12px;background:#fff}
6table{border-collapse:collapse}
7td{border:1px solid #333;padding:8px;vertical-align:top}
8img{width:56px;height:56px;display:block}
9</style></head><body>
10<table><tr>
12<td>cell text</td>
13</tr></table>
14</body></html>

PASS visually equivalent · no rejecting defect · thresholded evidence 0.008982% · raw 0.008982% (16 px) img-inline-block-descendant-sizing · inline-block-descendant-sizingPASS via CSS-scale observation: one-sided sub-CSS outline coverageMissingmissing 0.006085%ΔE 2.9

why: visually accepted coverage phase; raw candidate lacks paint present in reference (0.006085%)

An inline-block containing an img with explicit width and height:auto must preserve intrinsic aspect-ratio sizing and paint the replaced child.

regions (16 total; showing 16 representatives)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	14	14	12,12 → 32,32	1	total 0.03% · largest 0.002310%
Missing	2	2	27,27 → 32,32	1	total 0.004620% · largest 0.002310%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
Missing	32,27 → 32,27	0.002310		candidate lacks paint present in reference (0.002310%)
Missing	27,32 → 27,32	0.002310		candidate lacks paint present in reference (0.002310%)
AntialiasCoverage	25,12 → 25,12	0.002310	ΔRGB(12,8,4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	27,13 → 27,13	0.002310	ΔRGB(3,2,1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	17,14 → 17,14	0.002310	ΔRGB(15,10,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	16,15 → 16,15	0.002310	ΔRGB(-19,-12,-6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	15,16 → 15,16	0.002310	ΔRGB(-19,-12,-6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	14,17 → 14,17	0.002310	ΔRGB(15,10,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	12,25 → 12,25	0.002310	ΔRGB(12,8,4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	32,26 → 32,26	0.002310	ΔRGB(9,5,3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	13,27 → 13,27	0.002310	ΔRGB(3,2,1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	31,28 → 31,28	0.002310	ΔRGB(15,10,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	31,28 → 31,28	0.002310	ΔRGB(19,12,6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	28,31 → 28,31	0.002310	ΔRGB(19,12,6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	28,31 → 28,31	0.002310	ΔRGB(15,10,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	26,32 → 26,32	0.002310	ΔRGB(9,5,3)	antialiasing coverage residue on a shared outline

source · cases/images-replaced/img-inline-block-descendant-sizing.html

1<!doctype html>
2<html>
3<head>
4<meta charset="utf-8">
5<style>
6@page{size:152px 120px;margin:0}
7html{font-family:ParitySans;line-height:1.5}
8*{margin:0;box-sizing:border-box}
9html,body{background:#fff}
10body{padding:12px}
11.target{display:inline-block;border:2px solid #222;background:#f1f5f9;padding:6px;vertical-align:top}
12img{display:block;width:58px;height:auto}
13.after{display:inline-block;width:18px;height:18px;background:#00a651;margin-left:6px;vertical-align:top}
14</style>
15</head>
16<body>
18</body>
19</html>

PASS exact match img-border · border-on-image

A replaced image with a 6px solid border framing it under border-box sizing.

PASS exact match img-data-uri-intrinsic · data-uri-png-sized

A data: URI PNG placed in an img with explicit 120x120 size, scaled up from its 4x4 intrinsic pixels.

PASS exact match img-inline-block-descendant · inline-block-descendant

A raster img paints in normal flow and should also paint as a direct child of an inline-block; catches the inline-block text-collection path dropping replaced descendants.

PASS exact match img-intrinsic-natural · intrinsic-no-sizing

An img with no width/height attribute and no CSS sizing renders at its intrinsic 8x4 px natural dimensions (default sizing algorithm).

PASS exact match img-max-width-clamp · max-width-aspect-recompute

max-width:120px clamps a 200px-wide 2:1 image and recomputes its height from the aspect ratio to 60px.

PASS exact match img-width-height-stretch · explicit-width-height-stretch

A 1:1 intrinsic PNG given explicit width:200px and height:100px, stretching it non-uniformly.

PASS exact match svg-img-inner-rect · svg-no-viewbox-inner-rect

A no-viewBox SVG referenced as an img src is scaled into its display box; an inner rect at (40,40,200,140) scales with the viewport and stays centered with a blue margin rather than stretching to the image right/bottom edge.

PASS exact match svg-img-preserve-aspect-ratio-slice · svg-preserve-aspect-ratio-slice

An SVG image with preserveAspectRatio xMidYMid slice crops predictably in a square img slot; catches ignoring slice and fitting the whole SVG viewport.

inline-svg — 100.00% verified visual parity PASS 6 · FAIL 0 · REFERENCE-DISPUTED 0all categories ↑

PASS visually equivalent · no rejecting defect · thresholded evidence 0.08% · raw 0.08% (186 px) svg-inline-gradient-clip-path · gradient-clip-pathPASS via CSS-scale observation: sub-CSS shared-colour coverageAntialiasCoverageΔE 4.0

why: visually accepted coverage phase; raw antialiasing coverage residue on a shared outline

An inline SVG gradient-filled rect clipped by a clipPath paints only inside the circle; catches supporting gradients or clip paths separately but not together.

regions (150 total; showing 64 representatives)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	150	186	32,7 → 108,83	5	total 0.2% · largest 0.004072%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
AntialiasCoverage	52,79 → 53,79	0.004072	ΔRGB(-16,7,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	86,11 → 87,11	0.003257	ΔRGB(-15,8,12)	antialiasing coverage residue on a shared outline
AntialiasCoverage	73,7 → 73,7	0.001629	ΔRGB(-15,7,8)	antialiasing coverage residue on a shared outline
AntialiasCoverage	64,7 → 64,7	0.001629	ΔRGB(-15,6,7)	antialiasing coverage residue on a shared outline
AntialiasCoverage	56,9 → 57,9	0.001629	ΔRGB(-13,6,6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	83,9 → 84,9	0.001629	ΔRGB(-10,6,7)	antialiasing coverage residue on a shared outline
AntialiasCoverage	53,11 → 53,11	0.001629	ΔRGB(-14,6,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	52,11 → 53,11	0.001629	ΔRGB(-8,12,9)	antialiasing coverage residue on a shared outline
AntialiasCoverage	50,12 → 50,12	0.001629	ΔRGB(-5,6,4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	35,29 → 35,30	0.001629	ΔRGB(-3,5,2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	105,29 → 105,30	0.001629	ΔRGB(-12,5,10)	antialiasing coverage residue on a shared outline
AntialiasCoverage	34,31 → 34,32	0.001629	ΔRGB(-10,7,3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	107,35 → 107,35	0.001629	ΔRGB(-12,6,10)	antialiasing coverage residue on a shared outline
AntialiasCoverage	33,35 → 33,36	0.001629	ΔRGB(-9,6,2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	33,36 → 33,37	0.001629	ΔRGB(-8,5,3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	107,36 → 107,37	0.001629	ΔRGB(-15,7,12)	antialiasing coverage residue on a shared outline
AntialiasCoverage	32,50 → 32,50	0.001629	ΔRGB(-3,4,2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	108,50 → 108,50	0.001629	ΔRGB(-12,5,10)	antialiasing coverage residue on a shared outline
AntialiasCoverage	33,53 → 33,53	0.001629	ΔRGB(-3,4,2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	107,53 → 107,53	0.001629	ΔRGB(-12,6,10)	antialiasing coverage residue on a shared outline
AntialiasCoverage	33,54 → 33,54	0.001629	ΔRGB(-11,6,2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	34,58 → 34,58	0.001629	ΔRGB(-13,7,3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	35,60 → 35,60	0.001629	ΔRGB(-6,6,3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	105,60 → 105,60	0.001629	ΔRGB(-13,7,12)	antialiasing coverage residue on a shared outline
AntialiasCoverage	50,77 → 50,77	0.001629	ΔRGB(-9,7,4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	86,79 → 87,79	0.001629	ΔRGB(-15,11,16)	antialiasing coverage residue on a shared outline
AntialiasCoverage	84,80 → 84,80	0.001629	ΔRGB(-7,5,6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	57,81 → 57,81	0.001629	ΔRGB(-8,5,4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	83,81 → 83,81	0.001629	ΔRGB(-3,4,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	75,83 → 76,83	0.001629	ΔRGB(-8,3,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	73,83 → 73,83	0.001629	ΔRGB(-3,3,4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	68,7 → 68,7	0.000814	ΔRGB(-8,3,3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	72,7 → 72,7	0.000814	ΔRGB(-3,1,1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	65,7 → 65,7	0.000814	ΔRGB(-8,3,2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	65,7 → 65,7	0.000814	ΔRGB(-11,4,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	67,7 → 67,7	0.000814	ΔRGB(-31,12,12)	antialiasing coverage residue on a shared outline
AntialiasCoverage	75,7 → 75,7	0.000814	ΔRGB(-10,3,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	75,7 → 75,7	0.000814	ΔRGB(-3,1,1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	76,7 → 76,7	0.000814	ΔRGB(-17,7,9)	antialiasing coverage residue on a shared outline
AntialiasCoverage	76,7 → 76,7	0.000814	ΔRGB(-12,6,6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	61,8 → 61,8	0.000814	ΔRGB(-5,2,1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	62,8 → 62,8	0.000814	ΔRGB(-13,6,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	78,8 → 78,8	0.000814	ΔRGB(-14,5,7)	antialiasing coverage residue on a shared outline
AntialiasCoverage	78,8 → 78,8	0.000814	ΔRGB(-8,4,4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	60,8 → 60,8	0.000814	ΔRGB(-5,2,1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	80,8 → 80,8	0.000814	ΔRGB(-8,4,4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	59,8 → 59,8	0.000814	ΔRGB(-13,6,4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	80,8 → 80,8	0.000814	ΔRGB(-14,5,7)	antialiasing coverage residue on a shared outline
AntialiasCoverage	57,9 → 57,9	0.000814	ΔRGB(-9,4,4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	83,9 → 83,9	0.000814	ΔRGB(-5,2,3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	56,10 → 56,10	0.000814	ΔRGB(-15,7,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	84,10 → 84,10	0.000814	ΔRGB(-15,6,8)	antialiasing coverage residue on a shared outline
AntialiasCoverage	55,10 → 55,10	0.000814	ΔRGB(-16,6,6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	85,10 → 85,10	0.000814	ΔRGB(-15,6,8)	antialiasing coverage residue on a shared outline
AntialiasCoverage	54,10 → 54,10	0.000814	ΔRGB(-17,8,6)	antialiasing coverage residue on a shared outline
AntialiasCoverage	85,10 → 85,10	0.000814	ΔRGB(-16,6,9)	antialiasing coverage residue on a shared outline
AntialiasCoverage	52,12 → 52,12	0.000814	ΔRGB(-13,5,4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	88,12 → 88,12	0.000814	ΔRGB(-9,4,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	90,12 → 90,12	0.000814	ΔRGB(-21,8,11)	antialiasing coverage residue on a shared outline
AntialiasCoverage	49,13 → 49,13	0.000814	ΔRGB(-17,8,5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	91,13 → 91,13	0.000814	ΔRGB(-15,6,9)	antialiasing coverage residue on a shared outline
AntialiasCoverage	46,15 → 46,15	0.000814	ΔRGB(-5,2,2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	93,15 → 93,15	0.000814	ΔRGB(-11,5,7)	antialiasing coverage residue on a shared outline
AntialiasCoverage	43,18 → 43,18	0.000814	ΔRGB(-10,4,2)	antialiasing coverage residue on a shared outline

source · cases/images-replaced/svg-inline-gradient-clip-path.html

1<!DOCTYPE html>
2<html lang="en">
3<head>
4<meta charset="utf-8">
5<style>
6  @page { size: 184px 136px; margin: 0; }
7  html { font-family: ParitySans; line-height: 1.5; }
8  * { margin: 0; box-sizing: border-box; }
9  html, body { background: #ffffff; }
10  svg {
11    display: block;
12    width: 140px;
13    height: 90px;
14    background: #c62828;
15  }
16</style>
17</head>
18<body>
19  <svg viewBox="0 0 140 90" xmlns="http://www.w3.org/2000/svg">
20    <defs>
21      <linearGradient id="g" x1="0" x2="1">
22        <stop offset="0" stop-color="#0a7f2e"></stop>
23        <stop offset="1" stop-color="#1565c0"></stop>
24      </linearGradient>
25      <clipPath id="c">
26        <circle cx="70" cy="45" r="38"></circle>
27      </clipPath>
28    </defs>
29    <rect x="10" y="5" width="120" height="80" fill="url(#g)" clip-path="url(#c)"></rect>
30  </svg>
31</body>
32</html>

PASS visually equivalent · no rejecting defect · thresholded evidence 0.05% · raw 0.05% (436 px) svg-inline-clip · clip-path-circlePASS via CSS-scale observation: sub-CSS shared-colour coverageAntialiasCoverageΔE 3.9

why: visually accepted coverage phase; raw antialiasing coverage residue on a shared outline

Inline SVG rect clipped to a circle via a clipPath def, leaving a red disc.

regions (268 total; showing 64 representatives)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	268	436	20,20 → 139,139	6	total 0.1% · largest 0.001600%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
AntialiasCoverage	60,23 → 61,23	0.001600	ΔRGB(-3,-15,-15)	antialiasing coverage residue on a shared outline
AntialiasCoverage	23,60 → 23,61	0.001600	ΔRGB(-3,-15,-15)	antialiasing coverage residue on a shared outline
AntialiasCoverage	137,98 → 137,100	0.001600	ΔRGB(-2,-11,-11)	antialiasing coverage residue on a shared outline
AntialiasCoverage	98,137 → 100,137	0.001600	ΔRGB(-2,-11,-11)	antialiasing coverage residue on a shared outline
AntialiasCoverage	133,53 → 134,54	0.001333	ΔRGB(-4,-17,-17)	antialiasing coverage residue on a shared outline
AntialiasCoverage	53,133 → 54,134	0.001333	ΔRGB(-4,-17,-17)	antialiasing coverage residue on a shared outline
AntialiasCoverage	53,26 → 54,26	0.001067	ΔRGB(-4,-17,-17)	antialiasing coverage residue on a shared outline
AntialiasCoverage	52,26 → 52,27	0.001067	ΔRGB(-2,-12,-12)	antialiasing coverage residue on a shared outline
AntialiasCoverage	26,52 → 27,52	0.001067	ΔRGB(-2,-12,-12)	antialiasing coverage residue on a shared outline
AntialiasCoverage	133,52 → 133,52	0.001067	ΔRGB(-1,-4,-4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	26,53 → 26,54	0.001067	ΔRGB(-4,-17,-17)	antialiasing coverage residue on a shared outline
AntialiasCoverage	52,133 → 52,133	0.001067	ΔRGB(-1,-4,-4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	96,22 → 97,22	0.000800	ΔRGB(-3,-15,-15)	antialiasing coverage residue on a shared outline
AntialiasCoverage	98,23 → 99,23	0.000800	ΔRGB(-3,-17,-17)	antialiasing coverage residue on a shared outline
AntialiasCoverage	58,24 → 59,24	0.000800	ΔRGB(-3,-12,-12)	antialiasing coverage residue on a shared outline
AntialiasCoverage	101,24 → 101,24	0.000800	ΔRGB(-3,-15,-15)	antialiasing coverage residue on a shared outline
AntialiasCoverage	56,24 → 57,25	0.000800	ΔRGB(-3,-12,-12)	antialiasing coverage residue on a shared outline
AntialiasCoverage	104,25 → 105,25	0.000800	ΔRGB(-2,-14,-14)	antialiasing coverage residue on a shared outline
AntialiasCoverage	130,47 → 130,47	0.000800	ΔRGB(-3,-12,-12)	antialiasing coverage residue on a shared outline
AntialiasCoverage	24,56 → 25,57	0.000800	ΔRGB(-3,-12,-12)	antialiasing coverage residue on a shared outline
AntialiasCoverage	24,58 → 24,59	0.000800	ΔRGB(-3,-12,-12)	antialiasing coverage residue on a shared outline
AntialiasCoverage	136,58 → 136,59	0.000800	ΔRGB(-2,-11,-11)	antialiasing coverage residue on a shared outline
AntialiasCoverage	137,60 → 137,61	0.000800	ΔRGB(-3,-17,-17)	antialiasing coverage residue on a shared outline
AntialiasCoverage	137,63 → 138,63	0.000800	ΔRGB(-2,-10,-10)	antialiasing coverage residue on a shared outline
AntialiasCoverage	22,96 → 22,97	0.000800	ΔRGB(-3,-15,-15)	antialiasing coverage residue on a shared outline
AntialiasCoverage	23,98 → 23,99	0.000800	ΔRGB(-3,-17,-17)	antialiasing coverage residue on a shared outline
AntialiasCoverage	136,100 → 136,101	0.000800	ΔRGB(-2,-14,-14)	antialiasing coverage residue on a shared outline
AntialiasCoverage	24,101 → 24,101	0.000800	ΔRGB(-3,-15,-15)	antialiasing coverage residue on a shared outline
AntialiasCoverage	25,104 → 25,105	0.000800	ΔRGB(-2,-14,-14)	antialiasing coverage residue on a shared outline
AntialiasCoverage	47,130 → 47,130	0.000800	ΔRGB(-3,-12,-12)	antialiasing coverage residue on a shared outline
AntialiasCoverage	58,136 → 59,136	0.000800	ΔRGB(-2,-11,-11)	antialiasing coverage residue on a shared outline
AntialiasCoverage	100,136 → 101,136	0.000800	ΔRGB(-2,-14,-14)	antialiasing coverage residue on a shared outline
AntialiasCoverage	60,137 → 61,137	0.000800	ΔRGB(-3,-17,-17)	antialiasing coverage residue on a shared outline
AntialiasCoverage	63,137 → 63,138	0.000800	ΔRGB(-2,-10,-10)	antialiasing coverage residue on a shared outline
AntialiasCoverage	72,20 → 72,20	0.000533	ΔRGB(-2,-8,-8)	antialiasing coverage residue on a shared outline
AntialiasCoverage	70,20 → 70,20	0.000533	ΔRGB(-3,-12,-12)	antialiasing coverage residue on a shared outline
AntialiasCoverage	90,20 → 90,20	0.000533	ΔRGB(-2,-8,-8)	antialiasing coverage residue on a shared outline
AntialiasCoverage	91,21 → 91,21	0.000533	ΔRGB(-3,-15,-15)	antialiasing coverage residue on a shared outline
AntialiasCoverage	92,21 → 92,21	0.000533	ΔRGB(-3,-15,-15)	antialiasing coverage residue on a shared outline
AntialiasCoverage	64,22 → 64,22	0.000533	ΔRGB(-2,-11,-11)	antialiasing coverage residue on a shared outline
AntialiasCoverage	95,22 → 95,22	0.000533	ΔRGB(-3,-12,-12)	antialiasing coverage residue on a shared outline
AntialiasCoverage	63,22 → 63,22	0.000533	ΔRGB(-3,-17,-17)	antialiasing coverage residue on a shared outline
AntialiasCoverage	62,22 → 62,22	0.000533	ΔRGB(-3,-14,-14)	antialiasing coverage residue on a shared outline
AntialiasCoverage	99,23 → 100,23	0.000533	ΔRGB(-3,-12,-12)	antialiasing coverage residue on a shared outline
AntialiasCoverage	59,23 → 59,23	0.000533	ΔRGB(-2,-8,-8)	antialiasing coverage residue on a shared outline
AntialiasCoverage	100,23 → 100,23	0.000533	ΔRGB(-2,-12,-12)	antialiasing coverage residue on a shared outline
AntialiasCoverage	57,24 → 58,24	0.000533	ΔRGB(-2,-10,-10)	antialiasing coverage residue on a shared outline
AntialiasCoverage	102,24 → 102,24	0.000533	ΔRGB(-1,-5,-5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	103,24 → 103,24	0.000533	ΔRGB(-2,-10,-10)	antialiasing coverage residue on a shared outline
AntialiasCoverage	106,26 → 106,26	0.000533	ΔRGB(-3,-15,-15)	antialiasing coverage residue on a shared outline
AntialiasCoverage	106,26 → 107,26	0.000533	ΔRGB(-2,-8,-8)	antialiasing coverage residue on a shared outline
AntialiasCoverage	107,26 → 107,26	0.000533	ΔRGB(-4,-16,-16)	antialiasing coverage residue on a shared outline
AntialiasCoverage	112,29 → 113,29	0.000533	ΔRGB(-2,-10,-10)	antialiasing coverage residue on a shared outline
AntialiasCoverage	132,51 → 132,51	0.000533	ΔRGB(-2,-10,-10)	antialiasing coverage residue on a shared outline
AntialiasCoverage	134,55 → 134,55	0.000533	ΔRGB(-2,-11,-11)	antialiasing coverage residue on a shared outline
AntialiasCoverage	24,57 → 24,58	0.000533	ΔRGB(-2,-10,-10)	antialiasing coverage residue on a shared outline
AntialiasCoverage	136,58 → 136,58	0.000533	ΔRGB(-2,-8,-8)	antialiasing coverage residue on a shared outline
AntialiasCoverage	23,59 → 23,59	0.000533	ΔRGB(-2,-8,-8)	antialiasing coverage residue on a shared outline
AntialiasCoverage	137,61 → 137,61	0.000533	ΔRGB(-2,-8,-8)	antialiasing coverage residue on a shared outline
AntialiasCoverage	22,62 → 22,62	0.000533	ΔRGB(-3,-14,-14)	antialiasing coverage residue on a shared outline
AntialiasCoverage	137,62 → 137,62	0.000533	ΔRGB(-1,-5,-5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	22,63 → 22,63	0.000533	ΔRGB(-3,-17,-17)	antialiasing coverage residue on a shared outline
AntialiasCoverage	22,64 → 22,64	0.000533	ΔRGB(-2,-11,-11)	antialiasing coverage residue on a shared outline
AntialiasCoverage	138,66 → 138,66	0.000533	ΔRGB(-2,-11,-11)	antialiasing coverage residue on a shared outline

source · cases/images-replaced/svg-inline-clip.html

1<!DOCTYPE html>
2<html lang="en">
3<head>
4<meta charset="utf-8">
5<title>inline svg clip-path</title>
6<style>
7  @page { size: 384px 224px; margin: 0; }
8  html { font-family: ParitySans; line-height: 1.5; }
9  * { margin: 0; box-sizing: border-box; }
10  html, body { background: #ffffff; }
11  .stage {
12    width: 240px;
13    margin: 30px;
14    background: #eeeeee;
15  }
16  svg { display: block; }
17</style>
18</head>
19<body>
20  <div class="stage">
21    <svg width="160" height="160" viewBox="0 0 160 160" xmlns="http://www.w3.org/2000/svg">
22      <defs>
23        <clipPath id="c">
24          <circle cx="80" cy="80" r="60"></circle>
25        </clipPath>
26      </defs>
27      <rect x="0" y="0" width="160" height="160" fill="#c62828" clip-path="url(#c)"></rect>
28    </svg>
29  </div>
30</body>
31</html>

PASS visually equivalent · no rejecting defect · thresholded evidence 0.02% · raw 0.02% (206 px) svg-inline-shapes · rect-circle-path-viewboxPASS via CSS-scale observation: sub-CSS shared-colour coverageAntialiasCoverageΔE 3.2

why: visually accepted coverage phase; raw antialiasing coverage residue on a shared outline

Inline SVG with a rect, circle and triangle path under a 0 0 100 100 viewBox scaled to 200x200.

regions (146 total; showing 64 representatives)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	146	206	104,10 → 183,90	6	total 0.04% · largest 0.001280%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
AntialiasCoverage	179,31 → 180,32	0.001280	ΔRGB(-14,-9,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	179,67 → 180,68	0.001280	ΔRGB(-14,-9,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	156,12 → 156,12	0.000640	ΔRGB(-12,-7,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	157,12 → 157,12	0.000640	ΔRGB(-12,-7,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	161,14 → 162,14	0.000640	ΔRGB(-20,-12,-4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	108,32 → 108,32	0.000640	ΔRGB(-19,-12,-4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	106,36 → 106,37	0.000640	ΔRGB(-12,-7,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	106,37 → 106,38	0.000640	ΔRGB(-16,-10,-4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	182,38 → 182,38	0.000640	ΔRGB(-14,-9,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	182,61 → 182,62	0.000640	ΔRGB(-14,-9,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	106,61 → 106,62	0.000640	ΔRGB(-16,-10,-4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	106,63 → 106,63	0.000640	ΔRGB(-12,-7,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	108,67 → 108,68	0.000640	ΔRGB(-19,-12,-4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	161,86 → 162,86	0.000640	ΔRGB(-20,-12,-4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	157,87 → 157,88	0.000640	ΔRGB(-12,-7,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	156,88 → 156,88	0.000640	ΔRGB(-12,-7,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	155,11 → 155,11	0.000427	ΔRGB(-10,-6,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	132,12 → 132,12	0.000427	ΔRGB(-8,-6,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	131,12 → 131,12	0.000427	ΔRGB(-8,-6,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	159,13 → 159,13	0.000427	ΔRGB(-11,-7,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	126,14 → 126,14	0.000427	ΔRGB(-23,-14,-5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	125,14 → 126,14	0.000427	ΔRGB(-18,-12,-4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	162,14 → 162,14	0.000427	ΔRGB(-6,-3,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	108,31 → 108,32	0.000427	ΔRGB(-19,-12,-4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	180,34 → 180,34	0.000427	ΔRGB(-11,-7,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	107,35 → 107,35	0.000427	ΔRGB(-6,-3,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	181,36 → 181,36	0.000427	ΔRGB(-14,-9,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	181,63 → 181,63	0.000427	ΔRGB(-14,-9,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	107,65 → 107,65	0.000427	ΔRGB(-6,-3,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	180,66 → 180,66	0.000427	ΔRGB(-11,-7,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	108,68 → 108,68	0.000427	ΔRGB(-19,-12,-4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	125,85 → 126,85	0.000427	ΔRGB(-18,-12,-4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	162,85 → 162,85	0.000427	ΔRGB(-6,-3,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	126,86 → 126,86	0.000427	ΔRGB(-23,-14,-5)	antialiasing coverage residue on a shared outline
AntialiasCoverage	159,87 → 159,87	0.000427	ΔRGB(-11,-7,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	131,88 → 131,88	0.000427	ΔRGB(-8,-6,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	132,88 → 132,88	0.000427	ΔRGB(-8,-6,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	155,88 → 155,88	0.000427	ΔRGB(-10,-6,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	139,10 → 139,10	0.000213	ΔRGB(-4,-3,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	149,10 → 149,10	0.000213	ΔRGB(-8,-6,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	137,10 → 137,10	0.000213	ΔRGB(-8,-6,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	151,10 → 151,10	0.000213	ΔRGB(-4,-3,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	135,11 → 135,11	0.000213	ΔRGB(-8,-6,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	153,11 → 153,11	0.000213	ΔRGB(-4,-3,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	132,11 → 132,11	0.000213	ΔRGB(-6,-3,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	133,11 → 133,11	0.000213	ΔRGB(-16,-10,-4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	130,12 → 130,12	0.000213	ΔRGB(-6,-3,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	130,12 → 130,12	0.000213	ΔRGB(-18,-12,-4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	158,12 → 158,12	0.000213	ΔRGB(-11,-7,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	129,12 → 129,12	0.000213	ΔRGB(-12,-7,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	158,12 → 158,12	0.000213	ΔRGB(-15,-10,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	128,13 → 128,13	0.000213	ΔRGB(-6,-3,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	129,13 → 129,13	0.000213	ΔRGB(-19,-12,-4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	127,13 → 127,13	0.000213	ΔRGB(-10,-6,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	160,13 → 160,13	0.000213	ΔRGB(-12,-8,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	124,15 → 124,15	0.000213	ΔRGB(-8,-6,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	163,15 → 163,15	0.000213	ΔRGB(-14,-9,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	124,15 → 124,15	0.000213	ΔRGB(-16,-9,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	164,15 → 164,15	0.000213	ΔRGB(-11,-7,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	123,16 → 123,16	0.000213	ΔRGB(-10,-6,-2)	antialiasing coverage residue on a shared outline
AntialiasCoverage	165,16 → 165,16	0.000213	ΔRGB(-4,-3,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	120,18 → 120,18	0.000213	ΔRGB(-6,-3,-1)	antialiasing coverage residue on a shared outline
AntialiasCoverage	168,18 → 168,18	0.000213	ΔRGB(-12,-8,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	118,19 → 118,19	0.000213	ΔRGB(-8,-6,-2)	antialiasing coverage residue on a shared outline

source · cases/images-replaced/svg-inline-shapes.html

1<!DOCTYPE html>
2<html lang="en">
3<head>
4<meta charset="utf-8">
5<title>inline svg shapes</title>
6<style>
7  @page { size: 384px 264px; margin: 0; }
8  html { font-family: ParitySans; line-height: 1.5; }
9  * { margin: 0; box-sizing: border-box; }
10  html, body { background: #ffffff; }
11  .stage {
12    width: 240px;
13    margin: 30px;
14    background: #eeeeee;
15  }
16  svg { display: block; }
17</style>
18</head>
19<body>
20  <div class="stage">
21    <svg width="200" height="200" viewBox="0 0 100 100" xmlns="http://www.w3.org/2000/svg">
22      <rect x="5" y="5" width="40" height="40" fill="#2e7d32"></rect>
23      <circle cx="72" cy="25" r="20" fill="#1565c0"></circle>
24      <path d="M10 95 L50 55 L90 95 Z" fill="#c62828"></path>
25    </svg>
26  </div>
27</body>
28</html>

PASS exact match svg-inline-leaf-transform-matrices · leaf-transform-matrices

Transform matrices on SVG leaf paths position and orient four independently colored strokes; catches applying transforms only to SVG groups while discarding them on graphics elements.

PASS exact match svg-inline-linear-gradient · linear-gradient-fill

Inline SVG rect filled with a horizontal linearGradient from blue to red.

PASS exact match svg-inline-text · text-element

Inline SVG text element rendered in ParitySans at 36px over a light fill.

object-fit — 100.00% verified visual parity PASS 6 · FAIL 0 · REFERENCE-DISPUTED 0all categories ↑

PASS visually equivalent · no rejecting defect · thresholded evidence 0.30% · raw 0.30% (2496 px) img-object-fit-scale-down-shrink · scale-down-contain-winsPASS via CSS-scale observation: sub-CSS shared-colour coverageAntialiasCoverageΔE 9.1

why: visually accepted coverage phase; raw antialiasing coverage residue on a shared outline

object-fit:scale-down on a 240x120 image larger than a 160x160 box behaves like contain, shrinking it to 160x80 centred.

regions (3 total; showing 3 representatives)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	3	2496	0,0 → 160,160	2247	total 0.7% · largest 0.6%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
AntialiasCoverage	0,40 → 160,120	0.6	ΔRGB(15,8,-3)	antialiasing coverage residue on a shared outline
AntialiasCoverage	160,120 → 160,160	0.03	ΔRGB(-11,-11,-11)	antialiasing coverage residue on a shared outline
AntialiasCoverage	160,0 → 160,39	0.03	ΔRGB(-11,-11,-11)	antialiasing coverage residue on a shared outline

source · cases/images-replaced/img-object-fit-scale-down-shrink.html

1<!DOCTYPE html>
2<html lang="en">
3<head>
4<meta charset="utf-8">
5<title>img object-fit scale-down (contain wins)</title>
6<style>
7  @page { size: 384px 224px; margin: 0; }
8  html { font-family: ParitySans; line-height: 1.5; }
9  * { margin: 0; box-sizing: border-box; }
10  html, body { background: #ffffff; }
11  .stage { width: 240px; margin: 30px; background: #eeeeee; }
12  /* 240x120 (2:1) image larger than the 160x160 box: scale-down behaves like
13     contain, shrinking it to 160x80 centred (grey bands top and bottom). */
14  img {
15    display: block; width: 160px; height: 160px; background: #cccccc;
16    object-fit: scale-down; image-rendering: pixelated;
17  }
18</style>
19</head>
20<body>
21  <div class="stage">
23  </div>
24</body>
25</html>

PASS visually equivalent · no rejecting defect · thresholded evidence 0.06% · raw 0.06% (500 px) img-object-fit-none · nonePASS via CSS-scale observation: sub-CSS shared-colour coverageAntialiasCoverageΔE 2.6

why: visually accepted coverage phase; raw antialiasing coverage residue on a shared outline

object-fit:none draws the image at its intrinsic pixel size centred within the 160x160 box.

regions (1 total; showing 1 representative)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	1	500	160,0 → 160,160	500	total 0.1% · largest 0.1%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
AntialiasCoverage	160,0 → 160,160	0.1	ΔRGB(-11,-11,-11)	antialiasing coverage residue on a shared outline

source · cases/images-replaced/img-object-fit-none.html

1<!DOCTYPE html>
2<html lang="en">
3<head>
4<meta charset="utf-8">
5<title>img object-fit none</title>
6<style>
7  @page { size: 384px 224px; margin: 0; }
8  html { font-family: ParitySans; line-height: 1.5; }
9  * { margin: 0; box-sizing: border-box; }
10  html, body { background: #ffffff; }
11  .stage {
12    width: 240px;
13    margin: 30px;
14    background: #eeeeee;
15  }
16  /* object-fit none renders the image at intrinsic 8x4 px, centred in the 160x160 box. */
17  img {
18    display: block;
19    width: 160px;
20    height: 160px;
21    background: #cccccc;
22    object-fit: none;
23    image-rendering: pixelated;
24  }
25</style>
26</head>
27<body>
28  <div class="stage">
30  </div>
31</body>
32</html>

PASS visually equivalent · no rejecting defect · thresholded evidence 0.06% · raw 0.06% (500 px) img-object-fit-scale-down-none · scale-down-none-winsPASS via CSS-scale observation: sub-CSS shared-colour coverageAntialiasCoverageΔE 2.6

why: visually accepted coverage phase; raw antialiasing coverage residue on a shared outline

object-fit:scale-down on an 8x4 image smaller than the box picks none, drawing it at intrinsic size centred.

regions (1 total; showing 1 representative)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	1	500	160,0 → 160,160	500	total 0.1% · largest 0.1%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
AntialiasCoverage	160,0 → 160,160	0.1	ΔRGB(-11,-11,-11)	antialiasing coverage residue on a shared outline

source · cases/images-replaced/img-object-fit-scale-down-none.html

1<!DOCTYPE html>
2<html lang="en">
3<head>
4<meta charset="utf-8">
5<title>img object-fit scale-down (none wins)</title>
6<style>
7  @page { size: 384px 224px; margin: 0; }
8  html { font-family: ParitySans; line-height: 1.5; }
9  * { margin: 0; box-sizing: border-box; }
10  html, body { background: #ffffff; }
11  .stage { width: 240px; margin: 30px; background: #eeeeee; }
12  /* 8x4 (2:1) image far smaller than the 160x160 box: scale-down picks the
13     smaller of none and contain, so it renders at intrinsic 8x4 px centred. */
14  img {
15    display: block; width: 160px; height: 160px; background: #cccccc;
16    object-fit: scale-down; image-rendering: pixelated;
17  }
18</style>
19</head>
20<body>
21  <div class="stage">
23  </div>
24</body>
25</html>

PASS visually equivalent · no rejecting defect · thresholded evidence 0.03% · raw 0.03% (249 px) img-object-fit-contain · containPASS via CSS-scale observation: sub-CSS shared-colour coverageAntialiasCoverageΔE 2.6

why: visually accepted coverage phase; raw antialiasing coverage residue on a shared outline

object-fit:contain letterboxes a 2:1 image inside a 160x160 box, leaving grey bands top and bottom.

regions (2 total; showing 2 representatives)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	2	249	160,0 → 160,160	125	total 0.07% · largest 0.03%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
AntialiasCoverage	160,120 → 160,160	0.03	ΔRGB(-11,-11,-11)	antialiasing coverage residue on a shared outline
AntialiasCoverage	160,0 → 160,39	0.03	ΔRGB(-11,-11,-11)	antialiasing coverage residue on a shared outline

source · cases/images-replaced/img-object-fit-contain.html

1<!DOCTYPE html>
2<html lang="en">
3<head>
4<meta charset="utf-8">
5<title>img object-fit contain</title>
6<style>
7  @page { size: 384px 224px; margin: 0; }
8  html { font-family: ParitySans; line-height: 1.5; }
9  * { margin: 0; box-sizing: border-box; }
10  html, body { background: #ffffff; }
11  .stage {
12    width: 240px;
13    margin: 30px;
14    background: #eeeeee;
15  }
16  /* 2:1 image in a 160x160 box; contain letterboxes it to 160x80, centred vertically. */
17  img {
18    display: block;
19    width: 160px;
20    height: 160px;
21    background: #cccccc;
22    object-fit: contain;
23    image-rendering: pixelated;
24  }
25</style>
26</head>
27<body>
28  <div class="stage">
30  </div>
31</body>
32</html>

PASS exact match img-object-fit-cover · cover

object-fit:cover fills a 160x160 box with a 2:1 image, cropping its left and right edges.

PASS exact match img-object-fit-fill · fill

object-fit:fill stretches a 2:1 image to completely fill a 160x160 box, distorting its aspect.

object-position — 100.00% verified visual parity PASS 7 · FAIL 0 · REFERENCE-DISPUTED 0all categories ↑

PASS visually equivalent · no rejecting defect · thresholded evidence 0.78% · raw 0.86% (2463 px) img-object-position-far-edge-length · far-edge-length-coverPASS via CSS-scale observation: sub-CSS shared-colour coverageColorValueΔE 2.9

why: visually accepted coverage phase; raw fill recolour ΔRGB(+8,+1,-13) (ΔE 2.9)

object-position:right 20px bottom 10px offsets a cover-fitted image from far edges; catches parsing right 20px as plain right alignment.

regions (2 total; showing 2 representatives)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	2	2463	0,0 → 120,90	2182	total 2.3% · largest 2.1% · max ΔE 2.9

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
ColorValue	0,0 → 100,80	2.1	ΔRGB(8,4,-8)	fill recolour ΔRGB(+8,+4,-8) (ΔE 0)
AntialiasCoverage	120,0 → 120,90	0.3	ΔE 2.9 ΔRGB(-13,-13,-13)	antialiasing coverage residue on a shared outline

source · cases/images-replaced/img-object-position-far-edge-length.html

1<!DOCTYPE html>
2<html lang="en">
3<head>
4<meta charset="utf-8">
5<style>
6  @page { size: 192px 152px; margin: 0; }
7  html { font-family: ParitySans; line-height: 1.5; }
8  * { margin: 0; box-sizing: border-box; }
9  html, body { background: #ffffff; }
10  body { padding: 30px; }
11  .photo {
12    display: block;
13    width: 120px;
14    height: 90px;
15    background: #d9d9d9;
16    object-fit: cover;
17    object-position: right 20px bottom 10px;
18    image-rendering: pixelated;
19  }
20</style>
21</head>
22<body>
24</body>
25</html>

PASS visually equivalent · no rejecting defect · thresholded evidence 0.42% · raw 0.42% (657 px) img-object-position-far-edge-percent · far-edge-percent-coverPASS via CSS-scale observation: sub-CSS shared-colour coverageAntialiasCoverageΔE 34.1

why: visually accepted coverage phase; raw antialiasing coverage residue on a shared outline

object-position:right 25% bottom 25% offsets a cover-fitted image from far edges; catches treating far-edge percentages as plain 25% 25% or default center.

regions (1 total; showing 1 representative)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	1	657	32,0 → 32,70	657	total 1.1% · largest 1.1%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
AntialiasCoverage	32,0 → 32,70	1.1	ΔRGB(-99,45,3)	antialiasing coverage residue on a shared outline

source · cases/images-replaced/img-object-position-far-edge-percent.html

1<!DOCTYPE html>
2<html lang="en">
3<head>
4<meta charset="utf-8">
5<style>
6  @page { size: 144px 112px; margin: 0; }
7  html { font-family: ParitySans; line-height: 1.5; }
8  * { margin: 0; box-sizing: border-box; }
9  html, body { background: #ffffff; }
10  .slot {
11    width: 90px;
12    height: 70px;
13    overflow: hidden;
14    background: #c62828;
15  }
16  .slot img {
17    display: block;
18    width: 90px;
19    height: 70px;
20    object-fit: cover;
21    object-position: right 25% bottom 25%;
22    image-rendering: pixelated;
23  }
24</style>
25</head>
26<body>
27  <div class="slot">
29  </div>
30</body>
31</html>

PASS visually equivalent · no rejecting defect · thresholded evidence 0.09% · raw 0.09% (751 px) img-object-position-length · length-valuesPASS via CSS-scale observation: sub-CSS shared-colour coverageAntialiasCoverageΔE 14.7

why: visually accepted coverage phase; raw antialiasing coverage residue on a shared outline

object-position:10px 20px offsets a contained 2:1 image by absolute lengths from the box top-left.

regions (2 total; showing 2 representatives)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	2	751	10,0 → 160,160	500	total 0.2% · largest 0.1%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
AntialiasCoverage	160,0 → 160,160	0.1	ΔRGB(-4,-4,-4)	antialiasing coverage residue on a shared outline
AntialiasCoverage	10,20 → 10,100	0.07	ΔRGB(-152,-117,-3)	antialiasing coverage residue on a shared outline

source · cases/images-replaced/img-object-position-length.html

1<!DOCTYPE html>
2<html lang="en">
3<head>
4<meta charset="utf-8">
5<title>img object-position length</title>
6<style>
7  @page { size: 384px 224px; margin: 0; }
8  html { font-family: ParitySans; line-height: 1.5; }
9  * { margin: 0; box-sizing: border-box; }
10  html, body { background: #ffffff; }
11  .stage { width: 240px; margin: 30px; background: #eeeeee; }
12  /* contain letterboxes the 2:1 image to 160x80; object-position 10px 20px
13     offsets it 10px from the left edge and 20px from the top of the box. */
14  img {
15    display: block; width: 160px; height: 160px; background: #cccccc;
16    object-fit: contain; object-position: 10px 20px; image-rendering: pixelated;
17  }
18</style>
19</head>
20<body>
21  <div class="stage">
23  </div>
24</body>
25</html>

PASS visually equivalent · no rejecting defect · thresholded evidence 0.03% · raw 0.03% (249 px) img-object-position · bottom-with-containPASS via CSS-scale observation: sub-CSS shared-colour coverageAntialiasCoverageΔE 2.6

why: visually accepted coverage phase; raw antialiasing coverage residue on a shared outline

object-position:bottom anchors a contained 2:1 image to the bottom edge of a 160x160 box.

regions (1 total; showing 1 representative)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	1	249	160,0 → 160,79	249	total 0.07% · largest 0.07%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
AntialiasCoverage	160,0 → 160,79	0.07	ΔRGB(-11,-11,-11)	antialiasing coverage residue on a shared outline

source · cases/images-replaced/img-object-position.html

1<!DOCTYPE html>
2<html lang="en">
3<head>
4<meta charset="utf-8">
5<title>img object-position with contain</title>
6<style>
7  @page { size: 384px 224px; margin: 0; }
8  html { font-family: ParitySans; line-height: 1.5; }
9  * { margin: 0; box-sizing: border-box; }
10  html, body { background: #ffffff; }
11  .stage {
12    width: 240px;
13    margin: 30px;
14    background: #eeeeee;
15  }
16  /* contain letterboxes the 2:1 image to 160x80; object-position bottom anchors it to the box bottom. */
17  img {
18    display: block;
19    width: 160px;
20    height: 160px;
21    background: #cccccc;
22    object-fit: contain;
23    object-position: bottom;
24    image-rendering: pixelated;
25  }
26</style>
27</head>
28<body>
29  <div class="stage">
31  </div>
32</body>
33</html>

PASS visually equivalent · no rejecting defect · thresholded evidence 0.03% · raw 0.03% (249 px) img-object-position-percent · percentage-valuesPASS via CSS-scale observation: sub-CSS shared-colour coverageAntialiasCoverageΔE 2.6

why: visually accepted coverage phase; raw antialiasing coverage residue on a shared outline

object-position:25% 75% positions a contained 2:1 image within the free space of a 160x160 box.

regions (2 total; showing 2 representatives)

Complete component census grouped by dominant raster class; representative details are bounded.

Complete dominant-class aggregates

class	regions	pixels	union bbox (CSS px)	largest px	maximum magnitude
ColorErr	2	249	160,0 → 160,160	187	total 0.07% · largest 0.05%

Representative region details (worst-first)

class	bbox (CSS px)	area%	magnitude	reason
AntialiasCoverage	160,0 → 160,60	0.05	ΔRGB(-11,-11,-11)	antialiasing coverage residue on a shared outline
AntialiasCoverage	160,140 → 160,160	0.02	ΔRGB(-11,-11,-11)	antialiasing coverage residue on a shared outline

source · cases/images-replaced/img-object-position-percent.html

1<!DOCTYPE html>
2<html lang="en">
3<head>
4<meta charset="utf-8">
5<title>img object-position percentage</title>
6<style>
7  @page { size: 384px 224px; margin: 0; }
8  html { font-family: ParitySans; line-height: 1.5; }
9  * { margin: 0; box-sizing: border-box; }
10  html, body { background: #ffffff; }
11  .stage { width: 240px; margin: 30px; background: #eeeeee; }
12  /* contain letterboxes the 2:1 image to 160x80; object-position 25% 75%
13     anchors it 25% from the left and 75% from the top of the free space. */
14  img {
15    display: block; width: 160px; height: 160px; background: #cccccc;
16    object-fit: contain; object-position: 25% 75%; image-rendering: pixelated;
17  }
18</style>
19</head>
20<body>
21  <div class="stage">
23  </div>
24</body>
25</html>

PASS exact match img-object-fit-cover-default-center · cover-default-50-50

object-fit:cover with the default object-position 50% 50% splits the overflow evenly, showing the central strip of the image.

PASS exact match img-object-fit-cover-position · cover-left-top-crop

object-fit:cover with object-position:left top anchors the left edge of an overflowing 2:1 image, cropping its right half.
